This chapter introduces you to the type of practical electronics that you need to work correctly and effectively in interfacing electronic circuits with the Raspberry Pi (RPi) platform. The chapter begins by describing some equipment that can be very helpful in developing and debugging electronic circuits. It continues with a practical introductory guide to circuit design and analysis, in which you are encouraged to build the circuits and utilize the equipment that is described at the beginning of the chapter. The chapter continues with a discussion on the typical discrete components that can be interfaced to the general-purpose input/outputs (GPIOs) on the RPi, including diodes, capacitors, transistors, optocouplers, switches, and logic gates. Finally, the important principles of analog-to-digital conversion (ADC) are described, as such knowledge is required in Chapter 9 to build circuits that interface the RPi to analog sensors.

After completing this chapter, you should hopefully be able to do the following:

  • Describe the basic principles of electrical circuit operation, build circuits on breadboards, and measure voltage and current values.
  • Use discrete components such as diodes, LEDs, transistors, and capacitors in your own circuit designs.
  • Use transistors and FETs as switches to control higher current and voltage signals than would be possible by using the RPi outputs on their own.
  • Interconnect and interface to logic gates, being particularly aware of the issues that arise with “floating” inputs.
  • Describe the principles of analog-to-digital conversion and design basic operational-amplifier circuits.
  • Combine all of these skills to build the type of circuits that are important for safely interfacing to the RPi GPIOs.

Parts for this Chapter

Here is a full list of the components that are used in this chapter:

■ Breadboard
■ Diodes: 1N4001, general‐purpose LED
■ Transistors: NPN: BC547, FET: BS270
■ Voltage regulator: KA7805/LM7805
■ PTC: 60R110
■ Button and Switch: General purpose SPST and SPDT
■ ICs: 74HC73N, 74HC03N, 74LS08N, 74HC08N, 74HC14, LM358N
■ Resistors: 1 MΩ, 2.2 kΩ, 2×10 kΩ, 50 kΩ, 100 Ω, 50Ω, 1 kΩ, 470Ω, 220 Ω, 100 kΩ POT.
■ Capacitors: 10μF, 1μF, 0.33μF, 0.1μF.
■ Opto‐isolator: SFH617A
